Avaya IP500 V1 Control Unit Chassis (700417207)

Avaya IP500 V1 Control Unit Chassis Description:

The Avaya IP500 Control Unit is the main processing unit for the IP Office IP500 system. IP Office 4.2 or greater provides support for up to 384 users. The IP500 (700417207) supports a wide range of telephones but the following are designed to work with this system: 5400 series Digital phones and the 5600 series IP phones. This unit works well in small and midsized businesses and provides a choice of solutions to provide office and meet customer service requirements.

Avaya 700417207 Features:

• Supports up to 32 telephones - 16 analog trunks or 8 digital trunks.
• 4 Base Card Slots - Accommodates Digital Station, Analog Phone, VCM base cards, and the Legacy Card Carrier.
• Trunk Cards - Supports IP500 trunk daughter cards connected to IP500 Base Cards.  Also supports IP400 trunk cards using the Legacy Card Carrier.
• VCM Card Slots - Supports a maximum of 128 channels
• Voicemail Channels - Maximum 30 usable for Voicemail Pro/TAPI WAV connection sessions
• 8 Expansion Ports - Compatible with Digital Station 16/30, Phone 8/16/30,So8, WAN3, and Analog Trunk 16.
• 2 LAN Ports - Full duplex 10/100 Mbps; managed layer 3 Ethernet switch
• 1 Dedicated Feature Key Smart Card Slot - Used for Smart Card Feature Key.  Required for control unit use and activation of application licenses.
• Additional Ports - Music on-hold, DTE port, external relay switch for door entry controls, integral WAN port

Includes:

• (1x) Avaya IP500 V1 Control Unit Chassis (700417207)
