Avaya IP500 V2 Control Unit Chassis (700476005)

Avaya IP500 V2 Control Unit Chassis Description:

The Avaya 700476005 is the IP500 V2 Control Unit that features four base card / module slots for the IP Office System.  There is a multitude of card combinations that the 700476005 supports depending on your needs.

Avaya 700476005 Features:

• 4 Base Card / Module Slots
• Supports IP500 Digital Station 8, Analog Phone 2, Analog Phone 8, Combination ATM, ETR 6, TCM 8, VCM 32, VCM 64, 4-Port Expansion, and Legacy Card Carrier base cards
• Trunk Cards
• Supports IP500 ATM 4, PRI 1, and PRI 2 trunk interface cards installed on IP500 Base Cards
• Also supports IP400 ATM 4, 24 PRI T1, and 48 PRI T1 trunk interface cards using the Legacy Card Carrier
• 2 SD Card Slots
• Supports system SD card (required) and optional SD card
• Voicemail Channels
• Maximum 30 usable for Voicemail Pro/TAPI WAV connection sessions
• Eight Expansion Ports
• RJ45 Ssocket (Located On Back of Chassis)
• Support for up to 12 External Expansion Modules
• In addition to the 8 integrated expansion ports, you can add up to 4 additional expansion ports using the 4-Port Expansion base card
• One LAN Port / One WAN Port
• Full duplex 10/100 Mbps; managed layer 3 Ethernet switch
• 3.5mm Stereo Jack (MOH)
• Single RS232 Management Port
• Wall mountable with wall mounting kit (see related items)

Includes:

• (1x) Avaya IP500 V2 Control Unit Chassis (700476005)
